SP-UV2101 UV-Vis Spectrophotometer
Key Features of SP-UV2101 UV-Vis Spectrophotometer
- Wavelength Range: 190–1100 nm
- Spectral Bandwidth: 1.0 nm
- Optical System: Single beam with 1200 lines/mm grating
- Light Source: Imported Deuterium and Tungsten lamps
- Detector: Imported Silicon Photodiode
- Display: 10.1-inch high-resolution TFT colored capacitive touch screen (1024×600)
SP-UV2102 UV-Vis Spectrophotometer
Key Features of SP-UV2102 UV-Vis Spectrophotometer
- Wavelength Range: 190–1100 nm
- Spectral Bandwidth: 2.0 nm
- Optical System: Single beam with 1200 lines/mm grating
- Light Source: Tungsten lamp (HYBEC) and Deuterium lamp (Milaras)
- Detector: Silicon photodiode
- Display: 10.1-inch color capacitive touch screen (1024×600)
- Measurement Modes: Photometric, quantitative, spectrum scanning, kinetics, DNA/protein testing, multi-wavelength
- Data Storage: Internal memory with USB export capability
- Software Compatibility: Optional PC software adhering to GLP/GMP standards
- Sample Compartment: 4-cell holder for 10 mm cuvettes
SP-UV3101 UV-Vis Spectrophotometer
Key Features of SP-UV3101 UV-Vis Spectrophotometer
- Optical System: Double beam with 1200 lines/mm grating
- Wavelength Range: 190–1100 nm
- Spectral Bandwidth: 1.0 nm
- Display: 10.1-inch high-resolution color capacitive touch screen (1024×600)
- Measurement Modes: Photometric, quantitative, spectrum scanning, kinetics, DNA/protein testing, multi-wavelength
- Data Storage: Internal memory with USB export capability
- Software Compatibility: Optional PC software adhering to GLP/GMP standards
- Sample Compartment: 4-cell holder for 10 mm cuvettes
SP-UV3102 UV-Vis Spectrophotometer
Key Features of SP-UV3102 UV-Vis Spectrophotometer
- Optical System: Double beam with 1200 lines/mm grating
- Wavelength Range: 190–1100 nm
- Spectral Bandwidth: 2.0 nm
- Display: 10.1-inch high-resolution color capacitive touch screen (1024×600)
- Measurement Modes: Photometric, quantitative, spectrum scanning, kinetics, DNA/protein testing, multi-wavelength
- Data Storage: Internal memory with USB export capability
- Software Compatibility: Optional PC software adhering to GLP/GMP standards
- Sample Compartment: 4-cell holder for 10 mm cuvettes
SP-UV5102 UV-Vis Spectrophotometer
Key Features of SP-UV5102 UV-Vis Spectrophotometer
- Optical System: Double beam with 1200 lines/mm grating
- Wavelength Range: 190–1100 nm
- Spectral Bandwidth: 2.0 nm
- Light Source: Hamamatsu Xenon lamp (Japan)
- Detector: Silicon photodiode
- Display: 10.1-inch high-resolution color capacitive touch screen (1024×600)
- Measurement Modes: Photometric, quantitative, spectrum scanning, kinetics, DNA/protein testing, multi-wavelength
- Data Storage: Internal memory with USB export capability
- Software Compatibility: Optional PC software adhering to GLP/GMP standards
- Sample Compartment: 4-cell holder for 10 mm cuvettes
SP-V1000 Spectrophotometer
Key Features of SP-V1000 Spectrophotometer
- Wavelength Range: 325–1000 nm
- Spectral Bandwidth: 4.0 nm
- Photometric Range: -0.3 to 3.0 A, 0–200%T
- Light Source: Tungsten lamp (Japan HYBEC)
- Optical System: Single beam
- Data Storage: Up to 200 data groups and 200 standard curves
- Display: 128×64 dot-matrix backlit LCD
- Auto Wavelength Calibration: Yes
- Connectivity: USB and parallel port
- Software Compatibility: Optional 'Wave Professional' for PC control and advanced functions
- Sample Compartment: Accommodates 5–100 mm path length cuvettes with optional holders
SP-V1100 Visible Spectrophotometer
Key Features of SP-V1100 Visible Spectrophotometer
- Wavelength Range: 320–1100 nm
- Spectral Bandwidth: 2.0 nm
- Light Source: Tungsten lamp
- Optical System: Single beam
- Photometric Range: -0.3 to 3.0 A, 0–200%T
- Photometric Accuracy: ±0.002 A @ 0.5 A; ±0.004 A @ 1.0 A; ±0.3%T @ 100%T
- Photometric Repeatability: ≤0.001 A @ 0.5 A; ≤0.002 A @ 1.0 A; ≤0.15%T @ 100%T
- Wavelength Accuracy: ±0.5 nm
- Wavelength Repeatability: ≤0.3 nm
- Stability: ≤0.002 A/h @ 500 nm (after 2-hour preheat)
- Stray Light: ≤0.05%T @ 360 nm
- Sample Compartment: 4-position, 10 mm pathlength cuvette holder
- Display: LCD
- Data Storage: Stores up to 200 data groups and 200 standard curves; data recovery after power failure
- Connectivity: USB and parallel port for printer
- Software Compatibility: Optional 'Wave Professional' software for PC control, spectrum scanning, kinetics, multi-wavelength analysis, and nucleic acid/protein quantification
SP-XUV5101 UV-Vis Spectrophotometer
Key Features of SP-XUV5101 UV-Vis Spectrophotometer
- Optical System: Double beam with 1200 lines/mm grating
- Wavelength Range: 190–1100 nm
- Spectral Bandwidth: 1.0 nm
- Light Source: Hamamatsu Xenon lamp (Japan)
- Detector: Silicon photodiode
- Display: 10.1-inch high-resolution color capacitive touch screen (1024×600)
- Measurement Modes: Photometric, quantitative, spectrum scanning, kinetics, DNA/protein testing, multi-wavelength
- Data Storage: Internal memory with USB export capability
- Software Compatibility: Optional PC software adhering to GLP/GMP standards
- Sample Compartment: 4-cell holder for 10 mm cuvettes
